Reversible filter drier ZRK163 SAE 3/8″
180 RON
Model ZRK163 3/8″
- Tip: Reversible filter drier
- Size: 3/8″
- Working pressure (PS): 46 were
- Burst pressure: 175 bar
- Threaded connection – 3/8″ SAE.
21 in stock
Reversible filter drier ZRK163 SAE 3/8″
— is a high-quality device intended for use in heat pumps. It works in reversible cycle. It is designed to allow flow in the pump liquid line in both directions. This ZRK163 Reversible Filter Dryer is used for refrigerants R12, R22, R32, R502, R134a, R404A, R407C, R410A, R507. Also for CFC, HCFC, HFC and specific lubricants. Filtration capacity reaches 0.10 microns. The internal check valve, made of nylon, ensures filtration in both directions. The removal of organic and inorganic acids is achieved using activated aluminum oxide, and moisture is removed with a molecular dryer. The addition of activated carbon in the drying core helps to remove wax at low operating temperatures.
Technical features
| Filter reversible dehydrator ZRK163 | SAM |
|---|---|
| Working pressure (PS) | 46 were |
| Burst pressure | 175 were |
| CONNECTIONS | 3/8″ SAE |
The reversible filter drier model ZRK163 SAE has a solid core made of a mixture of molecular sieve and activated aluminum. These adsorbents are fixed in the core using a synthetic adhesive material. The core is tightly clamped on both sides, and cotton pads are placed for protection.
The retaining veins inside the filter direct the flow, which allows the fluid to operate in any direction in heat pumps. This construction ensures high filtration efficiency and water and acid absorption. The reversible filter drier ZRK084 is available with threaded connection SAE 3/8″.
We also offer models with 3/8″ ODF solder connection. For further details, please contact us.
❓ FAQ – Reversible filter drier ZRK163 SAE 3/8″
1. What is the ZRK163 SAE reversible filter drier?
Filter drier ZRK163 SAE 3/8″ is a component for heat pumps and refrigeration systems, designed for operation in reversible cycle, allowing refrigerant to circulate in both directions.
2. Where is ZRK163 SAE used?
This model is used in heat pumps, chillers and professional refrigeration systems, where circuit protection against moisture, acids and impurities is required.
3. What refrigerants is it compatible with?
ZRK163 SAE reversible filter drier is compatible with a wide range of refrigerants including R12, R22, R32, R134a, R404A, R407C, R410A, R507, as well as with agents from the classes CFCs, HCFCs and HFCs.
4. How does two-way filtering work?
Reversible operation is ensured by a valve internal din nylon, which directs the flow of refrigerant in any direction, maintaining filtration performance regardless of the heat pump's operating mode.
5. What level of filtration does the ZRK163 SAE offer?
The filter offers a filtration capacity of up to 0.10 microns, using a core made of molecular sieve and activated aluminum oxide, supplemented with activated carbon to reduce impurities and deposits.
6. What are the main technical characteristics?
- He would be: ZRK (reversible)
- Working pressure: 46 were
- Burst pressure: 175 were
- Connection: 3/8″ SAE
🔗 Similar products
- 👉 Reversible filter drier ZRK164 SAE 1/2″ – higher flow version for more powerful systems
- 👉 Filter drier KLE-305 SAE 5/8′′ – unidirectional version for the liquid line
- 👉 Freon sight glass with humidity indicator 3/8″ – monitoring the condition of the refrigerant
- 👉 Air-to-water heat pump 16 kW Premium
- 👉 Ground-water heat pump 9 kW
See another model
| Вес | 0.79 кг |
|---|---|
| Габариты | 18.0 × 7.9 × 7.9 см |
Specifications
Bidirectional filter model. SAE connection:
| Model | Connection | A | ΦB | ΦC | G | L | S. | For M | Weight (g) |
| SFK-163 | 3/8 SAE | 171 | F79 | F8 | 17 | 180 | 16 | 5/8-18UNF | 799 |
| SFK-164 | 1/2 SAE | 178 | F10 | 19 | 188 | 19 | 3/4-16UNF | 839 | |
| SFK-165 | 5/8 SAE | 189 | F13 | 23.5 | 201 | 22 | 7/8-14UNF | 893 | |
| SFK-303 | 3/8 SAE | 245 | F8 | 17 | 254 | 16 | 5/8-18UNF | 1303 | |
| SFK-304 | 1/2 SAE | 252 | F10 | 19 | 262 | 19 | 3/4-16UNF | 1334 | |
| SFK-305 | 5/8 SAE | 263 | F13 | 23.5 | 275 | 22 | 7/8-14UNF | 1294 | |
| SFK-306 | 3/4 SAE | 265 | F16 | 25 | 277 | 27 | 1-1/16-14UNF | 1352 |
